Simulation
SimLab Soft Simulation

  • Available in the Mechanical and Ultimate editions of SimLab Composer.
  • Developed for Engineers.
  • It’s represented as a workbench within SimLab Composer, which is accessible directly from the Workbenches Bar.
  • The Simulation Workbench is dedicated for executing physical and mechanical simulations within SimLab Composer application.





SimLab Soft Mechanical Simulation SimLab Soft Simulation
Simulation
SimLab Soft Simulation
Simulation Preview
SimLab Soft Simulation
SimLab Soft Simulation SimLab Soft Simulation
SimLab Soft Simulation
video

This video demonstrates an Interactive simulation showcase, created interactively, from SimLab Composer.


SimLab Soft Simulation
Simulation Workbench
SimLab Soft Simulation


Take your knowledge of Simulation to the next step by viewing the simulation tutorial.


SimLab Soft Simulation SimLab Soft Simulation
SimLab Soft Simulation
video

SimLab Soft Simulation
Simulation Tutorial
SimLab Soft Simulation
SimLab Soft Simulation SimLab Soft Mechanical Simulation
SimLab Soft Simulation
video

Get to know the easiest way to simulate and the most straight-forward application for simulation.



SimLab Soft Simulation
Simulation with VR
SimLab Soft Simulation


This is a showcase of an advanced mechanical simulation run inside a VR environment, the simulation shows a backhoe driven by the Chrono dynamic physics engine, and run in VR, simulation is created using SimLab Composer.






SimLab Soft Simulation SimLab Soft VR Simulation
SimLab Soft Simulation
video


Interactive simulation can be run in SimLab VR viewer (using HTC vive, Oculus or on the Desktop)






SimLab Soft Simulation SimLab Soft Simulation
SimLab Soft Simulation
video

>> Get in Simulation Fast with Various Ready-Made Models


The Models Library acts as a container for pre-installed simulation models that come with the Simulation Edition of SimLab Composer, distributed into three groups: Basic Physics Experiments, General, and Collision. As a start point, you can take a preview of what Simulation is capable of by start running the provided models.

Models Library

Dominoes

Dominoes

Engine

Engine

Flying Horse

Flying Horse

Four Bars

Free Call

Free Call

Geneva Rack

Geneva Rack

Mangle Rack

Mangle Rack

Mexican Wave

Mexican Wave

Motion Transmitter

Motion Transmitter

Multiple Gearing

Multiple Gearing

Multiple Geneva

Multiple Geneva

Oscillating

Oscillating

Pendulum

Pendulum

Pendulum and Ball

Pendulum and Ball

Pendulum Gear

Pendulum Gear

Projectile Motion

Projectile Motion

Rotary to Linear

Rotary to Linear

Slider Spring Mechanism

Slider Spring Mechanism

Stamp

Stamp

Straight Line Mechanism

Straight Line Mechanism


>> Straightforward Work-Flow


Main Steps for Passive Simulations

  1. Import a model
  2. Create solids
  3. Add joints
  4. Configure simulation parameters
  5. Run
  6. Trace or post-process results to plots (up to 4 simultaneously) or animation

Main Steps for Interactive Simulations

  1. Import a model
  2. Create solids
  3. Add joints
  4. Configure simulation parameters
  5. Design a control panel
  6. Plug a game controller (optional)
  7. Run and control interactively
  8. Trace or post-process results to plots (up to 4 simultaneously) or animation

>> Model Dynamic Mechanical Systems Using Basic Joints


Dynamic Mechanical Systems Using Basic Fixed Joints

Fixed

Dynamic Mechanical Systems Using Basic revolute Joints

Revolute

Dynamic Mechanical Systems Using Basic prismatic Joints

Prismatic

Dynamic Mechanical Systems Using Basic spherical Joints

Spherical

Dynamic Mechanical Systems Using Basic cylindrical Joints

Cylindrical

Dynamic Mechanical Systems Using Basic gear Joints

Gear

Dynamic Mechanical Systems Using Basic rack-pinion Joints

Rack and Pinion

Dynamic Mechanical Systems Using Basic pulley Joints

Pulley


>> Advanced Collision System


Advanced Collision System
  • A powerful physics engine that allows complex Rigid-Body simulations along with advanced collision detection capabilities.

>> Helpful and Informative Post-Processing


  • For the purpose of simulation data analysis and post processing, Plotting Library is provided by the Simulation Workbench as a graphical technique for representing a simulation data set as a graph, showing the relationship between two or more variables.
  • Results can be transformed to animations, to be rendered as movies or exported.
Plotting Library is provided by the Simulation Workbench

>> Want Further Control over Your Interactive Simulations? Use a Game Controller


Simulation xbox
Simulation Sony


  • Producing realistic motion.
  • It is introduced to help students of all disciplines of engineering that applies the principles of engineering, physics, design, manufacturing, and maintenance of mechanical systems, which involves the production and usage of mechanical power.
  • You can use SimLab Composer to model the dynamic behaviors of objects in 3-D space.


  • Prototypes testing and simulation by engineers.
  • Virtual applications for engineering students.
  • Educational (schools and universities).


  • Using the Simulation Workbench in SimLab Composer.
  • In SimLab Composer, every simulation case requires creating solids and Links (optional). A Link defines the relationship of two solids to each other. Consider these prerequisites when you start every simulation project.
